Output voltage

1 … 36 V

Output current

0 … 10 A

Output Power

360 W

Residual Ripple U

≤ 50 mV

Residual Ripple I

≤ 50 mA

Noise & Ripple (20 Hz~7 MHz)

≤ 5 mVrms / 50 mVp.p.

Set Resolution U

10 mV

Set Resolution I

10 mA

Accuracy U

+/- 1% + 5 dgt. < 5 V ; +/- 1% + 2 dgt. > 5 V

Accuracy I

+/- 1% + 5 dgt. < 0,5 A; +/-1% + 2 dgt. > 0,5 A

DISPLAY SPECIFICATION :

Display Size

8 cm (3.2”)

Display Dimensions

48 x 66 mm

Multi-Line Display

4 dtg.: Voltage, Current , Power

Display Type

Farb-TFT / Color-TFT

GENERAL SPECIFICATIONS :

Interfaces

USB host, USB device, RS-485, LAN

Operation Voltage

90 V – 264 VA C, 50/60 Hz

Power Factor Correction

>0,95 at optimal load

Energy efficiency (@ 230 V AC)

> 86%

Cooling

Fan Cooling

Dimensions (WxHxD)

193 x 98 x 215 mm

Weight

approx. 2,4 kg

EAN-13

4250569403842
