Technical Data

                Operating Voltage:   AC24…240V

                Current measuring range:   AC 2…20A

                Output max:   AC 500mA

                Output min:   AC 10mA

                Adjustment accuracy:   +/- 15%

                Repeat accuracy:   +/- 5%

                Hysteresis:   10% of value

                Release time:   On = <100ms…800ms, off =app. 1.5s

                Rated ambient temperature:   0…+55degC

                Dimensions (l x w x h):   50 x 36 x 56 mm

                Protection:   IP20

                Weight:   app. 90 g
