Gyrotork - Torque and angle gauge - GYROTORK

Technical Specification :

  • Torque transducer accuracy: 0.5% of the Full Scale
  • Angle sensor accuracy: 2%
  • Speed rate: 1 000 Hz
  • Resolution: 1/10 000 of the Full Scale
  • Units: Nm, kgcm, mNm, lbin, ozin, deg, tr
  • Internal memory : 2 000 results, 1 curve
  • Measurement mode: Track, Peak, Suivi, Pic, Breakaway, Angle @ Torque, Torque @ Angle
  • Operating life: 8 hours
Supplied with :
  • Gyrotork reference, capacity 15Nm, 60Nm ou 150Nm
  • Power supply 110V/220V
  • Calibration certificate
  • Carrying case
  • Data acquisition software Caligraph and USB cable
  • Operating manual
